Assembly lines for Tantalum capacitors

M203, M204 Bar welding module

Automatic Resistance welding line for Chip tantalum capacitors. composed of one M203 and one M204 Suitable for A,B,C,D,E type Complete line to weld tantalum capacitors on an aluminium bar by resistance weld. A special vision system and an SPC control allows to keep all the tolerances below 0.1 mm.

  • Cadence:more than 50.000 parts per hour


length: 135 cm
width: 115 cm
height: 185 cm


  • Resistance welding of tantalum wires on aluminium bar
  • AOI control of wire length at welding to have wire length tolerance below 0,01 mm.
  • Conveyor connected machines for minimum in order to have only one operator for entire line
  • Semi-automatic loading of carriers with anodes (Up to 1640 anodes in 60")
